This Y200 50mm TFS Easy Open End with Epoxy Phenolic Lacquer is food grade and tin free steel,they are used in different cans.
Brand:
SengKenOrder(MOQ):
100Payment:
50% T/T in advance.Product Origin:
ChinaColor:
OEM as per customer's requestShipping Port:
XiamenLead Time:
Depends on the quantityY401 Tinplate Easy Open End With Epoxy Phenolic Lacquer Gold Outside
This Plastic Easy Open Can Lid is food grade and tin free steel(TFS),they are used in different cans: tomato paste,cans meat,sea fish, tuna etc.
And we have several sizes for your option,see following:
Cover Type:
TFS Easy Open End : 200#,202#,209#,211#,214#,300#,304#,305#,307#,311#,315#,401#,502#,603#,902#
Hook Edge Outer Diameter:
Different cover typle has different outer diameter.
Hook Edge Height:
Different cover typle has different height.
Countersunk: Different cover typle has different countersunk.
Hook Edge Opening: Different cover typle has different opening.
Size |
CAN DIAMETER(MM) |
CHUNK DIAMETER(MM) |
COUNTERSINK DEPTH(MM) |
#200 | 50 | 49.5 | 3.6 |
#202 | 52 | 51.8 | 3.95 |
#211 | 65 | 64.9 | 3.95 |
#214 | 70 | 69.9 | 4.2 |
#300 | 73 | 72.16 | 4.2 |
#307 | 83 | 82.37 | 4.55 |
#315 | 95 | 94.13 | 4.61 |
#401 | 99 | 97.73 | 4.65 |
#603 | 153 | 153.40 | 5.30 |
Product Display:
